Unmanned Surface Vessels

Defining the Future of All-Domain Operations

MADE IN THE USA

OVERVIEW

In partnership with the leading USV manufacturer, Red Cat is proud to introduce its line of Unmanned Surface Vessels (USVs) with integrated sensors and kinetic-strike capabilities that redefine maritime autonomy and lethality. Our mission is to support national defense with innovative, mission-ready platforms – while playing a vital role in revitalizing the American maritime industry through advanced manufacturing, strategic partnerships, and unwavering commitment to U.S.-based innovation.

“This system has been used day in and day out in the current conflict, accumulating tens of thousands of hours in real combat operations and achieving dozens of successful kinetic engagements against enemy assets more than any navy since World War II.”

Jeff Thompson, CEO, Red Cat

5-Meter Variant

Introducing our 5-meter variant battle-proven Unmanned Surface Vessel (USV), to the U.S. and allied defense markets. Designed for speed, stealth, and precision, this variant delivers lethal strike capabilities in a compact, highly maneuverable platform built for today’s contested maritime environments.

BENEFITS
Designed for speed, stealth, and precision, the 5-meter variant delivers lethal strike capabilities in a compact, highly maneuverable platform built for today's contested maritime environments.
Its modular design supports a range of payloads—from kinetic strike packages to ISR and EW systems—enabling mission flexibility across surveillance, interdiction, and high-value target engagements.
As part of Red Cat’s integrated family of unmanned solutions, the 5-meter variant is engineered for multi-domain operations, working in tandem with our drone and autonomous technologies to deliver coordinated maritime and aerial dominance.
Manufactured in the United States, our line of unmanned service vessels support both national defense priorities and local economic growth, aligning with the U.S. Maritime Action Plan to revitalize American shipbuilding and unmanned systems innovation.
Not just a vessel—it’s a disruptive force multiplier for modern naval warfare.

SPECIFICATIONS
Maximum Operational Range: up to 450 nm at cruise speed
Endurance (Unmanned): 48+ hr continuous operation
Max Velocity (Combat Config): at least 50 kn
Sustained Operational Velocity: 23 kn
Sea State Operational Rating: SS3 (marginal), SS2 (optimal)
Mission Payload Capacity: up to 320 kg (705 lbs)
Sensor Package: Primary: EO/IR sensor suite with multi-axis stabilization | Secondary: Redundant EO/IR imaging systems
Command & Control: Multi-channel encrypted C2 datalinks with SatCom integration, COMSEC-compliant
Length Overall (LOA): 5.75m
Beam: 1.5m
Height (Keel to Highest Point): 1.0m
Displacement (Light/Full): 625/1450Kg
Propulsion Rating: 325Hp
Fuel Type: Petrol
Fuel Capacity: 550L
Propulsion System: Jet
Hull Construction: Maritime-grade composite fiberglass

Battle-Proven Lethality: Our USVs have a confirmed combat record with 10,000+ hours of operating time in live-combat missions.

U.S.-Based Manufacturing: All USV production will be based in the United States, directly supporting American manufacturing revitalization and job creation in alignment with national economic priorities.

Maritime Action Plan: Our go-to-market and manufacturing strategies are built to align with the current administration’s Maritime Action Plan Executive Order, addressing fleet modernization, national security, and maritime workforce development.

Multi-Domain Integration: Red Cat’s USVs are designed for seamless integration with our drone and ISR platforms, enabling true multi-domain operations across sea, air, and land for unified command and control.

Tactical Edge in Peer Conflicts: Our platforms offer high-speed, low-profile strike capabilities, giving operators a decisive edge in contested maritime environments—especially in the Asia Pacific.

Strike-Ready Modularity: Our USVs feature modular payload bays to accommodate a wide range of munitions, ISR packages, and EW tools—ready for mission-specific customization.

7-Meter Variant

The 7-meter variant is Red Cat’s next-generation Unmanned Surface Vessel (USV) developed to meet the demands of high-speed, long-range, kinetic maritime operations. This variant is built for larger payloads, extended endurance, and increased firepower.

BENEFITS
With its combat-tested design, the 7-meter variant delivers enhanced range, payload capacity, and mission flexibility, making it ideal for deep-strike missions, anti-ship warfare, and coastal interdiction in contested zones.
It integrates seamlessly with Red Cat’s suite of ISR and unmanned aerial systems, supporting multi-domain coordination and networked autonomous operations.
For naval commanders seeking powerful, proven, and scalable unmanned strike capabilities, the 7-meter variant offers an unmatched solution—designed for the fight, and ready to win it.

SPECIFICATIONS
Maximum Operational Range: up to 800 nm (standard payload)
Endurance (Unmanned): 60+ hr continuous operation
Max Velocity (Combat Config): at least 39+ kn
Sustained Operational Velocity: 23 kn
Sea State Operational Rating: SS4 (marginal), SS3 (optimal)
Mission Payload Capacity: up to 650 kg (1,433 lbs)
Sensor Package: Day/Night EO Targeting System with Enhanced Stabilization | Dual redundant imaging systems | Acoustic detection and classification suite
Command & Control: Multi-redundant encrypted C2 architecture with dual SatCom | uplinks, COMSEC-compliant
Length Overall (LOA): 7.2m
Beam: 2.1m
Height (keel to Highest Point): 1.5m
Displacement: (Light/Full): 1300/3400Kg
Propulsion Rating: 270Hp
Fuel Type: Diesel
Fuel Capacity: 1200L
Propulsion System: Hybrid Jet/Inboard Drive System
Hull Construction: Advanced Composite (HDPE/Fiberglass)
